The HT-S9300THX is that rare receiver/speaker system that combines all-in-one convenience with the quality assurance of THX. With Onkyo, you can take it for granted that you’ll be getting a smart amalgam of the latest processing and connectivity features. But what really sets the HT-S9300THX apart from other package systems is the sheer quality of the speakers. All seven of the front, center, surround, and surround back speakers feature woofer diaphragms made with Onkyo’s advanced A-OMF material. Driving the system is an A/V receiver that brings together a hand-picked selection of today’s most vital home entertainment technologies. Burr-Brown audio DACs work alongside PLL jitter-cleaning circuitry to get the best out of lossless Dolby and DTS formats, as well as the expanded height channels of Dolby Pro Logic IIz. Meanwhile, HDMI 1.4a brings 3D video compatibility, and Faroudja DCDi Cinema enables 1080p upscaling via HDMI of all video sources. Other highlights of this impressive system include powered Zone 2 audio and Audyssey room-correction.  Affordable THX certified quality in an all-in-one receiver-speaker package.
View larger. |
THX Certified Processing for Music, Movies, and Gaming
THX Integrated System (I/S) Plus is a category for home theater systems that ensures full-blown THX performance and state-of-the-art technologies in an affordable, all-in-one receiver-speaker package. Geared to gamers and budding audiophiles, THX I/S Plus systems are ideal for small home theaters where the screen-to-seat viewing distance is approximately eight feet. All components within the system—the receiver, speakers, and amplifier—are tested by THX to make sure they work harmoniously together. In addition to THX certification, each system comes with THX Surround EX; THX listening modes for music, movies, and games; and THX Loudness Plus, a volume-control technology for low-volume listening. Includes an all-in-one remote.
View larger. |
HDMI 1.4a Support for 3D Video and Audio Return Channel
The four HDMI 1.4a inputs on the HT-S9300THX’s A/V receiver let you simultaneously connect high-def sources such as a Blu-ray player, a gaming console,and a cable/satellite tuner. A single output then sends a pristine signal to your connected high resolution display. As the latest version of this connector, HDMI 1.4a adds the exciting possibilities of 3D video and an audio return channel. 3D video is the next big thing in home entertainment, with movie, game, and broadcast content on the increase and 3D-compatible TVs coming to market. This system also offers the convenience of an audio return channel via HDMI. Audio content received directly by your HDTV’s tuner can be sent "upstream" to the A/V receiver, without the need for a separate S/PDIF audio cable.HDMI Video Upscaling to 1080p with Faroudja Dcdi Cinema
When it comes to video processing, the Faroudja Dcdi Cinema (Directional Correlational Deinterlacing) video processor offers several advantages. This processor can accept any video signal, regardless of the source resolution, and upscale it to 1080p to match the native resolution of your high-definition display. What’s more, Dcdi Cinema effectively removes video artifacts such as jagged edges during the video signal deinterlacing process. You get to enjoy smooth progressive scan video images, even for fast-moving sports and action scenes. Dolby Pro Logic IIz Adds New Dimensions to Surround Sound
On the HT-S9300THX’s A/V receiver, Dolby Pro Logic IIz enables you to incorporate two "front height speakers into your surround-sound set-up as an alternative to the two surround back speakers. The front height channels carry ambient, nondirectional audio that helps immerse you even more deeply into your movies and games. A-OMF (Advanced Onkyo Micro Fiber) Diaphragm
Onkyo’s proprietary A-OMF diaphragms incorporate a PEN (polyethylene naphthalate) layer with a flexible cotton weave that helps to make them stronger and more resistant to heat. Speakers using this diaphragm type achieve improved mid-range clarity and imaging, which in turn produces an astonishingly vivid, natural sound.  Sleek, classic receiver styling with easy access to functionality.
View larger. |  130 Watts of power available on each channel, along with access to 4 HDMI inputs (1 out), component video and more.
View larger. |
Key Features- HT-R980 7.1-Channel Home Theater Receiver
- 130 Watts per channel at 6 Ohms, 1 kHz, 1%, 1 channel driven
- THX I/S Plus certified
- THX Loudness Plus, THX Surround EX, and THX listening modes (movies, music, games)
- HDMI (version 1.4a to support 3D and audio return channel) with Deep Color, x.v.Color, LipSync, Dolby TrueHD, DTS-HD Master Audio, DVDAudio, Super Audio CD, Multichannel PCM, and CEC
- Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, DTS-HD High-Resolution Audio Decoding
- HDMI video upscaling to 1080p with Faroudja Dcdi Cinema
- Dolby Pro Logic IIz for new surround channels
- Burr-Brown 192 kHz/24-Bit DACs (PCM1690) for all channels
- Three-stage inverted Darlington circuitry
- PLL jitter-cleaning circuit technology
- Audyssey 2EQ for room acoustic correction
- Audyssey Dynamic EQ for loudness correction
- Audyssey Dynamic Volume
- Powered Zone 2 and Zone 2 line-out for playback of separate source in another room
- Overlaid graphical on-screen display (OSD) via HDMI
- WRAT (Wide Range Amplifier Technology)
- H.C.P.S. (High Current Power Supply) massive high-power transformer
- Linear optimum gain volume circuitry
- Advanced 32-Bit processing DSP chip
- 4 DSP modes for gaming - rock, sports, action, and RPG (role playing game)
- Music Optimizer for compressed digital music files
- Direct mode
- Non-scaling configuration
- A-Form listening mode memory
- Theater-dimensional virtual surround function
- Universal port for single-cable connection of optional Onkyo dock for iPhone/iPod or HD Radio tuner
- Audio and 1080p video processing via HDMI (4 inputs and 1 output)
- HDTV-capable (720p/1080i) component video switching (2 inputs and 1 output)
- Front-panel audio input for portable devices
- Front-panel auxiliary A/V input
- 4 digital inputs (2 optical and 2 coaxial)
- 4 A/V inputs and 1 output
- Video output (monitor)
- 1 audio input
- Subwoofer pre out
- Color-coded, banana plug-compatible speaker posts (except front high or Zone 2)
- A/V sync control function (up to 200 ms in 10 ms steps)
- 40 FM/AM random presets
- RIHD (Remote Interactive over HDMI) for system control
- Compatible with RI (Remote Interactive) dock for iPod
- Preprogrammed RI remote control
- HTP-980 7.1-Channel Home Theater Speaker System*
- SKF-980 2-Way Acoustic Suspension Front Speakers
- 5" (12 cm) A-OMF diaphragm woofer x 2
- 1" (2.5 cm) soft-dome tweeter
- Max. input power - 130 W
- Magnetically shielded
- SKC-980 2-Way Acoustic Suspension Center Speaker
- 5" (12 cm) A-OMF diaphragm woofer x 2
- 1" (2.5 cm) soft-dome tweeter
- Max. input power - 130 W
- Magnetically shielded
- SKR-980/SKB-980 2-Way Acoustic Suspension Surround/Surround Back Speakers
- 5 1/8" (13 cm) A-OMF diaphragm woofer
- 1" (2.5 cm) soft-dome tweeter
- Max. input power - 130 W
- SKW-980 Acoustic Suspension Powered Subwoofer
- 12" (30 cm) Cone
- Rated output power - 125 W minimum continuous power (6 Ohms, 100 Hz, Maximum 1% THD)
- Output level control
What's in the Box
1-Onkyo HT-R980 7.1-Channel Home Theater Receiver, 2-SKF-980 2-Way Acoustic Suspension Front Speakers, 1-SKC-980 2-Way Acoustic Suspension Center Speaker, 2-SKR-980 2-Way Acoustic Suspension Surround Speakers, 2-SKB-980 2-Way Acoustic Surround Back Speakers, 1-SKW-980 Acoustic Suspension Powered Subwoofer, 1-indoor FM antenna, 1-AM loop antenna, speaker cables and labels, 1-speaker setup microphone, subwoofer cable, color-coded speaker cable, 1-instruction manual, 1-quick setup guide, 1-remote controller, AA (R6) batteries (2). Technical Specifications AV Receiver- Amplifier Section
- Power Output
- Front L/R - 130 W/Ch (6 ohms, 1 kHz, 1%, 1 channel driven))
- Center - 130 W (6 ohms, 1 kHz, 1%, 1 channel driven))
- Surround L/R - 130 W/Ch (6 ohms, 1 kHz, 1%, 1 channel driven))
- Surround Back L/R, Front High L/R, or Zone 2 L/R - 130 W/Ch (6 ohms, 1 kHz, 1%, 1 channel driven))
- Dynamic power - 180 W (3 ohms, front), 160 W (4 ohms, front), 100 W (8 ohms, front)
- THD (Total Harmonic Distortion) - 0.08% (1 W)
- Damping factor - 60 (Front, 1 kHz, 8 ohms)
- Input sensitivity and impedance - 200 mV/47 k-ohms (line)
- Output level and impedance - 200 mV/2.2 k-ohms (rec out)
- Rated RCA output level and impedance - 200 mV/470 ohms (pre out)
- Frequency response - 5 Hz-100 kHz/+1 dB, -3 dB (DSP bypass)
- Tone control - ±10 dB, 50 Hz (bass), ±10 dB, 20 kHz (treble)
- Signal-to-noise ratio - 106 dB (Line, IHF-A)
- Speaker impedance - 6 ohms-16 ohms
- Video Section
- Input sensitivity/output level and impedance video
- 1.0 Vp-p/75 ohms (component and s-video Y)
- 0.7 Vp-p/75 ohms (component PB/CB, PR/CR)
- 1.0 Vp-p/75 ohms (composite)
- Component video frequency response - 5 Hz-100 MHz/0 dB, -3 dB
- Tuner Section
- Tuning frequency range
- FM: 87.5 MHz-107.9 MHz
- AM: 530 kHz-1,710 kHz
- FM/AM preset memory - 40 stations
- General
- Power supply - AC 120 V~, 60 Hz
- Power consumption - 4.9 A
- Dimensions (W x H x D) - 17 1/8" x 5 15/16" x 12 15/16" (435 x 151.5 x 328.5 mm)
- Weight 19.0 lbs. (8.6 kg)
| Speaker System- Speaker type
- Front - 2-way, Acoustic suspension
- Center - 2-way, Acoustic suspension
- Surround - 2-way, Acoustic suspension
- Surround Back - 2-way, Acoustic suspension
- Subwoofer - Acoustic suspension, powered
- Drivers
- Front/Center - 5½ (12 cm) A-OMF diaphragm woofer x 2 / 1½ (2.5 cm) Soft-dome tweeter
- 5⅜" (13 cm) A-OMF diaphragm woofer / 1" (2.5 cm) Soft-dome tweeter
- 12" (30 cm) cone
- Frequency response
- Front/Center - 50 Hz–45 kHz
- Surround/Surround Back - 50 Hz–45 kHz
- Subwoofer - 20 Hz–100 Hz
- Sensitivity - Front/center (83 dB/W/m); Surround/Surround Back (81 dB/W/m)
- Max. input power - Front/Center/Surround/Surround Back (130 W)
- Rated output power - Subwoofer (125 W)
- Nominal impedance - Front/Center/Surround/Surround Back (8 ohms)
- Input sensitivity/impedance - Subwoofer - 330 mV/100 k-ohms
- General
- Dimensions (W x H x D)
- Front - 6 1/4" x 17 1/16" x 7 13/16" (158 x 433 x 199 mm)
- Center - 17 1/16" x 6 1/4" x 7 13/16" (433 x 158 x 199 mm)
- Surround/Surround Back - 7 7/8" x 10 13/16" x 6 5/8" (200 x 275 x 169 mm)
- Subwoofer - 14 15/16" x 17 1/2" x 16 7/8" (380 x 444 x 429 mm)
- Weight
- Front - 11.7 lbs. (5.3 kg)
- Center - 11.7 lbs. (5.3 kg)
- Surround/Surround Back - 7.7 lbs. (3.5 kg)
- Subwoofer - 34.2 lbs. (15.5 kg)
Carton- Dimensions (W x H x D) - 29 7/16" x 42 3/16" x 20 3/16" (748 x 1072 x 513 mm)
- Weight - 135.6 lbs. (61.5 kg)
|
*Note: All speakers feature an impedance of 8 ohms, color-coded speaker terminals and cable, and wall-mounting capability. |
